VA3
Feature
・ 48m/min X,Y and Z axis rapid traverse rate, max. spindle speed 20,000min-1
・ The spindle is separated from the ATC arm and the tool magazine
・ Since the tool magazine is fixed to the column top, the position of magazine will not affect the tooling area, only the spindle moves up and down so that tooling design becomes easy
・ 20 tools can be stored in the tool magazine as standard (Maximum mountable tool number:21 tools)
・ The tool can be inserted directly into the spindle or remove from the spindle manually from the front of the machine, storing tool into the tool magazine will be easy
Feature
| Machine tool parameter | VA3 |
| X/Y/Z axis stroke | 500×400×350mm |
| Table size | 650×400mm |
| Max. load on table | 250kg |
| Main spindle speed | 200～20,000min-1 |
| Main spinlde motor | 9.0/3.7kW |
| Tool shank | JIS B 6339-1998 BT30 |
| Width×Depth×Height | 1,500×2,180×2,501mm |
| Weight | 2,600kg |
For special requirements on technical specifications, please consult with the company's sales branches or legitimate distributors.
