金年会 Machining Centre
VA2
Feature
・ Optimum for high-speed and high-efficiency machining of small workpiece
・ Super compact machine of 1,040mmwide, productivity improvement per space
・ High speed tool change by double arm type ATC
・ 40m/min X,Y and Z axis rapid traverse rate realizes the high speed machining
Feature
| Machine tool parameter | VA2 |
| X/Y/Z-axis stroke | 360×260×250mm |
| Table size | 500×330mm |
| Max. load on table | 200kg |
| Main spindle speed | 300～30,000min-1(Normal highest spindle speed 28,000min-1) |
| Main spindle motor | 9.0/5.5kW |
| Main spindle taper | 7/24 taper S20T |
| Width×Depth×Height | 1,040×2,016×2,000mm |
| Weight | 1,800kg |
For special requirements on technical specifications, please consult with the company's sales branches or legitimate distributors.
